Maintenance
9403−5/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
25/ 38
94569
94569a
1
1
Blank flange
to fuel pump with
4 Screws M12x50 and
1 O-ring 42.52x2.62 mm
X = 93 mm
Blank flange
to valve housing at fuel rail with
4 Screws M12x80
X
1
= 92 mm
016.650/08
X
X
1
94575 1 Adjusting scale
(for Heinzmann StG 10-01 Actuator)
for regulating linkage
X = 120 mm
including:
701.013.610
013.610/05
X
94575a 1 Adjusting pin
(for Heinzmann StG 10-01 Actuator)
X = 51 mm
701.013.611
013.611/05
X
94583 1 Pipe
for pressure built-up in fuel rail after
commissioning
X = 475 mm
X
013.612/05
94584 1 Lifting plate
for removal and fitting of injection
control unit,
including 2 screws M10x25
X = 126 mm
(WLL 130 kg)
X
701.013.613
013.613/05
2011-01
Standard Tools
