Maintenance0360−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 3
Group Component Execution kg
3306 Connecting rod shank 996
Lower bearing half for bottom end
bearing with studs
complete 137
3310 Lower bearing shell half for bottom end
bearing
Upper bearing shell half for bottom end
bearing
16
23
3312 Bearing cover for top end bearing 151
3315 Bearing shell for top end bearing 39
3326 Crosshead without guide shoes
Crosshead with guide shoes complete
1066
1464
3403 Piston with piston rod and piston rod
gland
Piston crown
Piston skirt
Piston rod
Spraying plate with oil pipe
complete 1011
242
39
588
38
3603 Inside (telescopic) pipe to piston
cooling and crosshead lubrication
19
4
4106 Gear wheel on crankshaft
2-part, complete
375
579
4120 Intermediate wheel with bearing pins
and bearings for supply unit
Bearing pair for intermediate wheel
complete 315
51
4325 Shut-off valve for starting air 207
5
5552 Supply unit with pumps, driving wheels
Servo oil pump
Camshaft with gear wheel
complete
5−6 Cyl. engines
7−8 Cyl. engines
5−6 Cyl. engines
7−8 Cyl. engines
1750
2000
150
168
189
5556 Fuel pump complete 162
5564 Injection control unit complete 102
5612 Exhaust valve drive complete 29
Individual Components per Piece in kg
2011-12 / 50−D
