Introducing Blackmagic URSA
Blackmagic URSA PL model with Blackmagic URSA Viewfinder.
Blackmagic URSA is designed for single or multi user operation. While it's very easy to use
Blackmagic URSA as a single operator, your URSA features a dedicated DOP station on one
side, and camera assist and audio stations on the other to cater for shoots with larger crews. All
of URSA’s setup menus are available simultaneously from the touchscreen on either side of the
chassis, leaving the large 10 inch viewfinder free for composition and playback.
Blackmagic URSA’s touchscreen menus are designed for ease of use, providing a simple
scrolling interface with features categorised by the functions that different stations might use.
Blackmagic URSA’s 10 inch viewfinder offers a large, clear image preview. Status text is minimal
as additional information is easily available on the DOP and camera assist and audio stations.
Blackmagic URSA’s user interface is clean and simple, with features
divided by functions that each station of the camera might use.
SDI OUT
12V OUT
IRIS
L R
REF IN
TIMECODE IN
TIMECODE OUT
12V
CH1
SOLO
CH1
MUTE
CH2
MUTE
CH2
SOLO
FOCUS
PEAK
DISP
MENU
SLATE
0
-6
-12
-18
-24
-30
-36
-42
-48
SDI OUT
SDI IN
AUDIO IN
2
ZOOM
F1
F2
F3
DISP
PEAK
6Introducing Blackmagic URSA
