CAPINTEC, INC. CAPTUS
®
4000e
November 16 DICOM 17-11
Port
This indicates the TCP/IP port number of the DICOM Modality Worklist Provider.
(e.g., "104")
Service List
The service list is automatically filled in. It should only be changed by support
personnel.
Echo Button
This button performs a DICOM Echo using the information configured on this page
and the local DICOM settings page to test the DICOM association to the Worklist
Provider. The results are displayed in the test window next to the echo button.
After entering the data, select the Echo button to confirm that the DICOM SERVER is
communicating with the CAPTUS
®
4000e. The message “Successful Echo, Success”
will be displayed as shown in Figure 17-10.
Figure 17-10
Select the Save button to save the changes or select the Cancel button to cancel the
changes.
