AlterPath ACS Installation, Administration, and User’s Guide 169
Network
Figure 8-5: Expert > PCMCIA Modem Card Configuration Dialog Box
The following table provides a brief description of the fields available in the
Modem dialog box.
If you click the PPP checkbox, additional fields for a local and remote IP
address and a “Call Back” checkbox appear, as shown in the following figure.
Table 8-3: Expert > Form Fields for a Modem Card
Field Name Definition
[PCMCIA Card]
Pull-down menu to select the type of PCMCIA
card that you are using.
PPP
Check box to enable point-to-point protocol.
Local IP
The local IP address of the PCMCIA card.
Remote IP
The remote IP address of the PCMCIA card.
Call Back
Check box to enable the callback security feature.
Phone Number
The phone number that the ACS uses to call back.
