Cyclades AlterPath ACS - Figure 1-3: Alterpath ACS Family of Advanced Console Servers

AlterPath ACS Installation, Administration, and User’s Guide 9
The following figure illustrates the AlterPath ACS family of advanced
console servers.
Figure 1-3: AlterPath ACS family of advanced console servers
AlterPath ACS8
8 ATP0120 ATP0130
AlterPath
ACS16
16 ATP0010 ATP0050
AlterPath
ACS32
32 ATP0100 ATP0150
AlterPath
ACS48
48 ATP0190 ATP0200
Table 1-1: Model Numbers and Configuration Options
Model Number Serial Ports Single Power Supply
Part Number
Dual Power Supply
Part Number
