Network Menu & Forms
178
The following table provides a brief description of the fields available in the
Compact Flash/Hard Disk dialog box.
Table 8-7: Expert > Form Fields for a Compact Flash/Hard Disk
T To Configure a Compact Flash PCMCIA Card or a PCMCIA
Hard Disk Drive
1. Install the compact flash card or the hard disk drive and select “Compact
Flash/Hard Disk” from the pull-down menu on the PCMCIA
Management form.
The “Enable” checkbox appears on the Slot dialog box.
2. Click the “Enable” checkbox.
The “Use for data buffering” checkbox appear on the Slot dialog box.
3. If desired, uncheck the “Use for data buffering” checkbox. Default is
checked.
4. Click OK.
5. Click “apply changes.”
Configuring a Wireless LAN PCMCIA Card
You can use the “PCMCIA Management” form under “Network” to configure
a Wireless LAN PCMCIA card. When you select “Wireless LAN” from the
pull-down menu, the dialog box shown in the following figure appears.
Field Name Definition
[PCMCIA Card]
Select Compact Flash/Hard Disk from the Pull-
down menu.
Enable
Check box to enable the storage device.
Use for Data
Buffering
Check box to use the storage device for data
buffering.
