Network Menu & Forms
202
The following table defines the fields and menu options in the “TCP Options
Section.
”
Table 8-14: Expert > TCP Options Fields
UDP Protocol Fields
If UDP is selected as a protocol when specifying a rule, the additional fields
shown in the following figure appear at the bottom of the form.
Figure 8-34:Firewall Configuration “Add Rule” and “Edit Rule” UDP
Protocol Fields
The following table defines the fields in the UDP Options Section.
Field/Menu Option Definition
Source Port
- OR -
Destination Port
-AND-
to
A port number for filtering in the “Source Port” or “Destination
Port” field. A range of IP address can be specified by adding a
second port number in the “to” field. TCP packets are filtered for
for the range of specified IP addresses.
TCP Flags
The TCP flags cause packets to be filtered for the specified flag
and the selected condition. The flags are: “SYN” (synchronize),
“ACK” (acknowledge), “FIN” (finish), “RST” (reset), “URG”
(urgent) or “PSH” (push), and the conditions are either “Any,”
“Set,” or “Unset.”
Inverted
By checking this box, The TCP options are "Inverted". "Inverting"
an item negates the selected rules. Rules will apply to everything
except the selected options.
Table 8-15: Expert > UDP Options Fields
Field Definition
