Cyclades AlterPath ACS - Figure 8-13: Expert > PCMCIA Wireless LAN Card Configuration Dialog Box; Table 8-8: Expert > Form Fields for a Wireless LAN Card

AlterPath ACS Installation, Administration, and User’s Guide 179
Network
Figure 8-13: Expert > PCMCIA Wireless LAN Card Configuration Dialog
Box
The following table provides a brief description of the fields available in the
Wireless LAN dialog box.
Table 8-8: Expert > Form Fields for a Wireless LAN Card.
Field Name Definition
[PCMCIA Card]
Pull-down box to select the type of PCMCIA
card that you are using.
IP Address
The local IP address of the Ethernet.
Network Mask
The network address of the Ethernet.
MyPrivateNet
(ESSID)
The unique identifier for the wireless access
point.
Channel
The communication channel with the access
point.
Encrypted
The translation of data into code during
transmission.
