AlterPath ACS Installation, Administration, and User’s Guide 181
Network
Figure 8-14: Expert > PCMCIA CDMA Card Configuration Dialog Box
CDMA cards are modem cards that makes it possible for ACS to receive a
dial-in connection and support callback feature using the "ppp" protocol.
The following table provides a brief description of the fields available in the
CDMA dialog box.
Table 8-9: Expert > Form Fields for a CDMA Card.
Field Name Definition
[PCMCIA Card]
Pull-down box to select the type of PCMCIA
card that you are using.
Local IP
The local IP address of the CDMA card used
by the ppp connection.
Remote IP
The remote IP address of the CDMA card used
by the ppp connection.
Speed
The speed used by ACS to access the card.
