FIVE-SPEED MANUAL TRANSAXLE 5B–33
DAEWOO M-150 BL2
D13B735A
13. Install the counter shaft bearing shim.
D Measure clearance between the transaxle case
surface and the bearing outer race using a
straight ruler and gauge.
D Select shim in order that clearance is within stan-
dard.
Unit : mm (in.)
Measured value (A)
Shim thickness
0.33 − 0.37 (0.0130 – 0.0146)
0.45 (0.0177)
0.38 − 0.42 (0.0147 – 0.0165)
0.50 (0.0197)
0.43 − 0.47 (0.0169 – 0.0185)
0.55 (0.0217)
0.48 − 0.52 (0.0189 – 0.0205)
0.60 (0.0236)
0.53 − 0.57 (0.0209 – 0.0224)
0.65 (0.0256)
0.58 − 0.62 (0.0228 – 0.0244)
0.70 (0.0276)
0.63 − 0.67 (0.0248 – 0.0264)
0.75 (0.0295)
0.68 − 0.72 (0.0268 – 0.0283)
0.80 (0.0315)
0.73 − 0.77 (0.0287 – 0.0303)
0.85 (0.0335)
0.78 − 0.82 (0.0307 – 0.0323)
0.90 (0.0354)
0.83 − 0.87 (0.0327 – 0.0343)
0.95 (0.0374)
0.88 − 0.92 (0.0346 – 0.0362)
1.00 (0.0394)
0.93 − 0.97 (0.0366 – 0.0382)
1.05 (0.0413)
0.98 – 1.02 (0.0386 – 0.0402)
1.10 (0.0433)
1.03 – 1.07 (0.0406 – 0.0421)
1.15 (0.0453)
a. Straight ruler
b. Bearing outer race
c. Case surface
D13B736A
14. Install the side cover plate and the counter shaft fifth
gear.
D Install the side cover plate (1).
Tighten
Tighten the screws to 6–7 N.m (53–62 lb–in).
Important: Use only new screws.
D Install the counter shaft fifth gear (2).
Important: Position the machined boss side toward the
side cover plate.
To Next Page
