1‑86
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 4 Restart Printer 003-356
Is the "ADDR: 38
∗∗
"
displayed?
NoYes
Possible causative parts:TRANSFER BELT (PL4.1.1)
PWBA HVPS (PL5.1.17)
FUSER (PL6.1.10)
PWBA EEPROM STD (PL13.5.1)
PWBA MCU (PL13.5.13)
Reseat the PWBA
EEPROM.
Checking the failure parts.
Press the "
S
", "
T
" and "
3
" keys
after 003-356 error occurred
Does the error still
occur when turning
on the power?
NoYes
Replace the PWBA
EEPROM.
END
Is the "ADDR: 3C
∗∗
"
displayed?
NoYes
Reseat the FUSER
ASSY.
Does the error still
occur when turning
on the power?
NoYes
Replace the FUSER
ASSY.
END
A
