Dell 3115CN - Page 113

1‑87
Chapter 1 Troubleshooting
Version 2 2007.05.22
A
Is the "ADDR: 3A
∗∗
"
displayed?
NoYes
Reseat the TRANSFER
BELT.
Does the error still
occur when turning
on the power?
NoYes
END
REPLACE the
TRANSFER BELT.
Is the "ADDR: 31
∗∗
"
displayed?
NoYes
Reseat the HVPS.
Does the error still
occur when turning
on the power?
NoYes
Replace the HVPS.
(Removal 32/
Replacement 14)
Reseat the PWBA
MCU.
Does the error still
occur when turning
on the power?
NoYes
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
END
END
