FIP-1. 5 Restart Printer 004-310
NoYes
Possible causative parts:PWBA MCU (PL9.1.20)
OPTION FEEDER ASSY (PL12.1.1)
Checking the Optional Tray
installing
Reseat the Optional Tray.
(Removal 42/Replacement 4)
Checking after replacing the
Optional Tray
Replace the Optional Tray.
(Removal 42/Replacement 4)
No
Yes
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
Does the error still
occur when turning
on the power?
END
Does the error still
occur when turning
on the power?
END
