Chapter 1 Troubleshooting
Version 1 2006.11.21
A
Checking after replacing the
DRIVE ASSY MAIN.
Replace the DRIVE ASSY
MAIN. (Removal
36/Replacement 10)
NoYes
Replace the
PWBA MCU .
(Removal
67/Replaceme
nt 55)
Checking the Deve Motor for
operation.
NoYes
Does the Deve Motor rotate
normally?
Checked by [Digital Output] -
[DO-f] in [IOT
Diagnosis].
Does the error still
occur when turning on
the power?
END
Checking after replacing the
corresponding CARTRIDGE
ASSY
Replace the CARTRIDGE
ASSY .
Does the error still
occur when turning on
the power?
NoYes
END
Replace the
ROS ASSY.
(Removal
34/Replaceme
nt 12)
