Chapter 1 Troubleshooting
Version 1 2006.11.21
FIP-1. 16 Insert Fuser 010-317
*1: Some external noise is suspected. Go to [FIP-1. 87 Electrical Noise] to check for any noise
disturbance.
NoYes
Possible causative parts:FUSER ASSY (PL6.1.10)
PWBA MCU (PL9.1.20)
Checking FUSER ASSY installation
Is FUSER ASSY
installed correctly?
Reseat the FUSER
ASSY. (Removal 8/
Replacement 38)
Does the error still
occur after several
ON/OFF operations
of power?
NoYes
END *1
Checking after replacing
the FUSER ASSY.
Replace the FUSER ASSY.
(Removal 8/Replacement
38)
Yes
No
Does the error still
occur when the power
is turned ON?
END
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
