Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 17 Replace Fuser 010-351/Restart Printer 010-351
Does the error still
occur when turning
on the power?
NoYes
Possible causative parts:FUSER ASSY (PL6.1.10)
PWBA MCU (PL9.1.20)
Checking after replacing
the FUSER ASSY
Replace the FUSER ASSY.
Checking the FUSER
ASSY installation
Reseat the FUSER ASSY.
Does the error still
occur when turning
on the power?
NoYes
END
END
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
Is the life counter
going to reach the
replacement time?
NoYes
Replace the FUSER
ASSY.
Checking the fuser life
counter.
