1‑103
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 19 Restart Printer 010-377/010-378/010-379/010-380/010-381/010-382/010-383/
010-384/010-385/010-386/010-387/010-388/010-389/010-390/010-391/
010-392/010-393/010-394/010-395/010-396/010-397
Does the error still
occur when turning
on the power?
NoYes
Possible causative parts:FUSER ASSY (PL6.1.10)
LVPS (PL13.5.14)
PWBA MCU (PL9.1.20)
Checking after replacing
the FUSER ASSY
Replace the FUSER ASSY.
Checking the FUSER ASSY installation
Reseat the FUSER ASSY.
Does the error still
occur when turning
on the power?
NoYes
END
END
Checking after replacing
the LVPS
Replace the LVPS.
(Removal 65/Replacement
57)
Does the error still
occur when turning
on the power?
NoYes
END
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
