Dell 3115CN - Page 134

1‑108
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 23 Restart Printer 016-330/016-331/016-332/016-333/016-334/016-335/016-336/
016-337/Restart Printer 016-360/Network Error 016-770
No
Yes
Possible causative parts:Multi Protocol Card (option)
PWBA ESS (PL13.4.20)
Checking the
MPC installation
Reseat the MPC.
Does the error still
occur when turning
on the power?
END
Checking after
replacing the MPC.
Replace the MPC.
NoYes
Replace PWBA
ESS. (Removal 61/
Replacement 61)
Does the error still
occur when turning
on the power?
END
Checking the MPC
firmware version.
Print the system setting
report.
Is the MPC firmware
version on the wired
Network 12,15 or
later?
NoYes
Download the firmware
from the DELL web site.
