Dell 3115CN - Page 135

1‑109
Chapter 1 Troubleshooting
Version 1 2006.11.21
FIP-1. 24 Restart Printer 016-338
No
Yes
Possible causative parts:Option Wireless Printer Adapter
Option MPC Board
Checking the Connected device
to the USB port on the MPC.
Checking the Wireless
Printer Adapter
installation
Reseat the Wireless
Printer Adapter.
NoYes
Is the Wireless
Printer Adapter
connected to the USB
port on the MPC?
Replace the MPC Board.
Does the error still
occur when turning
on the power?
END
Connect the Wireless
Printer Adapter to the
USB port on the MPC.
NoYes
Checking after replacing
the Wireless Printer
Adapter
Replace the Wireless
Printer Adapter.
Does the error still
occur when turning
on the power?
END
NoYes
Checking the MPC
Board installation
Reseat the MPC Board.
Does the error still
occur when turning
on the power?
END
