1‑111
Chapter 1 Troubleshooting
Version 1 2006.11.21
FIP-1. 26 Restart Printer 016-370
NoYes
Possible causative parts:PWBA MCU (PL9.1.20)
PWBA ESS (PL13.4.20)
Checking the PWBA
ESS installation.
Reseat the PWBA ESS.
(Removal 61/
Replacement 61)
Checking the PWBA MCU
installation.
Reseat the PWBA MCU.
(Removal 67/Replacement
55)
NoYes
Does the error still
occur when turning
on the power?
END
Does the error still
occur when turning
on the power?
END
Checking after replacing
the PWBA ESS.
Replace the PWBA ESS.
(Removal 61/Replacement
61)
No
Yes
Does the error still
occur when turning
on the power?
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
END
