FIP-1. 30 Restart Printer 062-320/062-324
Possible causative parts: PWBA HYUI (PL13.4.1)
ADF SCANNER ASSY (PL13.8.1)
Checking the connector
connection
Reseat the connectors (P/
J60,62,63,64,65) on the
PWBA HYUI.
Does the error still
occur when turning
on the power?
NoYes
Checking after replacing
the ADF SCANNER ASSY
Replace the ADF
SCANNER ASSY.
(Removal 72/Replacement
50)
Does the error still
occur when turning
on the power?
NoYes
END
Replace the PWBA HYUI.
(Removal64/Replacement
58)
END
