1‑114
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 29 Restart Printer 062-311/062-321/062-360/062-371/117-352
Possible causative parts: PWBA HYUI (PL13.4.1)
ADF SCANNER ASSY (PL13.8.1)
Checking the scanner lock
Is the scanner lock at
the free position?
NoYes
Checking the connector
connection
Reseat the connectors (P/
J60,62,63,64,65) on the
PWBA HYUI.
Does the error still
occur when turning
on the power?
NoYes
END
Checking after replacing
the ADF SCANNER ASSY
Replace the ADF
SCANNER ASSY.
(Removal 72/Replacement
50)
Does the error still
occur when turning
on the power?
NoYes
END
Replace the PWBA HYUI.
(Removal64/Replacement
58)
Set the scanner lock to the
free position.
To Next Page
