Chapter 1 Troubleshooting
Version 1 2006.11.21
B
A
Checking the Regi Sensor
for operation
No
Yes
Checking the DRIVE ASSY
PH for operation
Does the number
on the screen increase by one,
every time the actuator of the regi
sensor is operated?
Checked by [Digital Input]-[DI-3]
in [IOT Diagnosis].
No
Yes
Checking the Feed Clutch
for operation
No
Yes
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
Replace the DRIVE ASSY
PH. (Removal 15/
Replacement 31)
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
Does the DRIVE ASSY PH
operate properly?
Checked by [Digital Output]-[DO-
a] in [IOT Diagnosis].
Does the feed clutch operate
properly?
Checked by [Digital Output]-[DO-
2f] in [IOT Diagnosis].
