Chapter 1 Troubleshooting
Version 1 2006.11.21
B
Checking the feed roll for
shape and operation
Remove the paper
cassette.
No
Yes
Checking the after
replacing the 250 PAPER
CASSETTE.
Replace the 250 PAPER
CASSETTE..
No
Yes
Checking the after
replacing the KIT FEEDER
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
END
No
END
Are feed rollers installed
correctly?
Also are they not conterminated
or damaged, and rotate smoothly?
Check these items by turning
them with your fingers.
Does the error still occur
when printing?
Does the error still occur
when printing?
Yes
Replace the PWBA MCU.
(Removal 67/Replacement
55)
Replace the KIT ROLLER.
If error occurred, replace
the KIT FEEDER.
(Removal 16/Replacement
30)
