Chapter 1 Troubleshooting
Version 1 2006.11.21
No
Yes
Replace the PWBA
ESS. (Removal 61/
Replacement 61)
Checking after replacing the
ROS ASSY
Replace the ROS ASSY.
(Removal 34/Replacement 12)
Is the image printed
correctly?
END
D
Checking the HVPS installation
Reseat the HVPS.
Is the image printed
correctly?
NoYes
END
No
Yes
Checking the PWBA HYUI
installation
Reseat the PWBA HYUI.
(Removal 64/Replacement 58)
Is the image printed
correctly?
END
