FIP-1.N3 During Printing
No
Yes
Possible causative parts:KIT SEPARATOR ROLLER ASSEMBLY (PL2.1.99)
KIT SEPARATOR AND FEED ROLLER (PL2.2.99)
BELT UNIT (PL4.1.1)
CARTRIDGE ASSY (PL5.1.18/PL5.1.19/PL5.1.20/PL5.1.21)
FUSER ASSY (PL6.1.10)
DRIVE ASSY MAIN (PL8.1.2)
DRIVE ASSY PH (PL8.1.7)
CHUTE ASSY DUP (PL11.1.1)
550 OPTION FEEDER (PL13.7.1)
KIT ADF FEED ROLLER (PL13.8.99)
Checking the MSI
Checking the paper
condition
Replace the standard
paper with a new and dry
one
Does the noise arise
when feeding the paper
from the MSI?
No
Yes
Replace the SEPARATOR
ROLLER ASSEMBLY.
(Removal 38/Replacement
8)
END
A
Does the noise arise
from the printer?
Checking the feeder
No
Yes
Does the noise
arise when feeding
the paper from the
feeder?
Checking the paper
condition
Replace the standard
paper with a new and dry
one
No
Yes
Replace the SEPARATOR
ROLLER. 250: (Removal
39/Replacement 7) 550:
(Removal 45/Replacement
1)
END
Does the noise arise
from the printer?
