1‑310
Chapter 1 Troubleshooting
Version 1 2006.11.21
FIP-DC
NoYes
Checking the connector of
LVPS connecting
Disconnect the power code
and wait for one minute.
Reseat the all connectors
of LVPS.
Is the printer
working?
END
NoYes
Checking the connector of
CONTROL PANEL
connecting.
Reseat the connector (P/
J202) of CONTROL PANEL.
Is the CONTROL
PANEL working?
END
NoYes
Checking the PWBA HYUI
installation
Reseat the PWBA HYUI.
(Removal 64/Replacement
58)
Is the printer
working?
END
Replace the LVPS.
(Removal 65/
Replacement 57)
