1‑35
Chapter 1 Troubleshooting
Version 1 2006.11.21
EOR
(End of Retransmission)
A signal sent out by the sending side in ECM mode to notify that the
retransmission request (PPR) for the same block has been received
for the predetermined number of times (typically four times) and that
the sending side will discontinue the retransmission of the relevant
block.
Appears as one of the following depending on the sending side sta-
tus.
EOR.NULL A signal sent out by the sending side in ECM mode to notify that the
retransmission request (PPR) for the same block has been received
for the predetermined number of times and the sending side will dis-
continue the retransmission of the relevant block, but that the trans-
mission of the subsequent block will be started.
EOR.EOP A signal sent out by the sending side in ECM mode to notify that the
retransmission request (PPR) for the same block has been received
for the predetermined number of times and the sending side will dis-
continue the retransmission of the relevant block, but that the entire
document has already been transmitted.
EOR.PEOP An EOR.EOP signal that requires operator intervention.
EOR.MPS A signal sent out by the sending side in ECM mode to notify that the
retransmission request (PPR) for the same block has been received
for the predetermined number of times and the sending side will dis-
continue the retransmission of the relevant block, but that one or
more pages of the document will remain unsent.
EOR.PMPS An EOR.MPS signal that requires operator intervention.
EOR.EOM A signal sent out by the sending side in ECM mode to notify that the
retransmission request (PPR) for the same block has been received
for the predetermined number of times and the sending side will dis-
continue the retransmission of the relevant block, but that one page
of the document has been transmitted and the subsequent page is
to be transmitted using different parameters (image quality, etc).
EOR.PEOM An EOR.EOM signal that requires operator intervention.
ERR
(Response to End of Retransmission)
A signal sent out by the receiving side to notify that any EOR signal
was received.
CTC
(Continue to Correct)
A signal sent out by the sending side in ECM mode to notify that the
sending side will continue to retransmit the requested block at a
newly set signaling rate, as a response to the retransmission
request (PPR) received for the same block for the predetermined
number of times.
CTR
(Response to Continue to Correct)
A signal sent out by the receiving side to notify that a CTC signal
was received.
RNR
(Receive Not Ready)
A signal sent out by the receiving side in ECM mode to request the
sending side to hold on the image data transmission until the receiv-
ing side becomes ready for reception.
RR
(Receive Ready)
A signal sent out by the sending side to notify that an RNR signal
was received.
CRP
(Command Repeat)
A signal sent out by the receiving side to notify that the previous sig-
nal was received in error and should be retransmitted.
PIP
(Procedural Interrupt Positive)
A signal sent out by the receiving side to notify that the image data
was successfully received but that further transmissions are not pos-
sible without operator intervention.
PIN
(Procedural Interrupt Negative)
A signal sent out by the receiving side to notify that the image data
was not received satisfactorily (detected unacceptable errors) and
that further transmissions are not possible without operator interven-
tion.
Signal Name Description
