Dell PowerConnect 8024 User Guide

Configuring System Information 231
File Upload
Use the File Upload to Server page to upload configuration (ASCII), image (binary), operational log,
and startup log files from the device to the server.
To display the File Upload to Server page, click System
→ File Management → File Upload in the tree
view.
Figure 6-109. File Upload to Server
The File Upload to Server page contains the following fields:
• File Type — Select the type of file to be uploaded. Possible filetypes are:
–
Firmware — Uploads the active image.
–
Configuration — Uploads the configuration file. If File Type - Configuration is selected, the
Transfer File Name field is also displayed.
–
Startup Log — Uploads the startup log file.
–
Operational Log — Uploads the operational log.
•
Transfer Mode — Select the transfer mode to upload the file to the server. The options are:
–
TFTP — Trivial File Transfer Protocol
–
SFTP — SSH File Transfer Protocol
Table 6-50. Downloading Files Commands
CLI Command Description
copy Copies files from a source to a destination.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
