Configuring Routing 561
•
Network Address
— The IP route prefix for the destination.
•
Subnet Mask
— Also referred to as the subnet/network mask, this indicates the portion of the IP
interface address that identifies the attached network.
•
Protocol
— This field tells which protocol created the specified route. The possibilities are one of the
following:
–Local
– Static
–Default
–OSPF Intra
–OSPF Inter
–OSPF Type-1
–OSPF Type-2
–RIP
•
Next Hop Interface
— The outgoing router interface to use when forwarding traffic to the destination.
•
Next Hop IP Address
— The outgoing router IP address to use when forwarding traffic to the next
router (if any) in the path towards the destination. The next router is always one of the adjacent
neighbors or the IP address of the local interface for a directly attached network.
Displaying the Router Route Table Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• IP Routing Commands
The following table summarizes the equivalent CLI commands for this feature.
Best Routes Table
Use the Router Best Routes Table
page to display the best routes from the routing table.
To display the page, click Routing
→
Router
→
Best Routes Table in the tree view.
Table 9-31. Router Route Table Commands
CLI Command Description
show ip route Displays the routing table.
show ip route summary Shows the number of all routes, including best and non-best routes.
