572 Configuring Routing
VRRP Configuration
Use the VRRP Configuration page to enable or disable the administrative status of a virtual router.
To display the page, click Routing
→ VRRP → Router Configuration in the tree view.
Figure 9-42. VRRP Configuration
The VRRP Configuration page contains the following field:
• Admin Mode — Select Enable from the drop-down menu to administratively enable VRRP on the
system.
Configuring VRRP Global Settings Using CLI Commands
For information about the CLI commands that perform this function, see the following chapters in the
CLI Reference Guide:
• Virtual Router Redundancy Protocol Commands
The following table summarizes the equivalent CLI commands for this feature.
Table 9-37. VRRP Global Commands
CLI Command Description
ip vrrp Enables the administrative mode of VRRP for the router.
show ip vrrp Displays whether VRRP functionality is enabled or disabled on the
switch.
