Dell PowerConnect 8024 User Guide

130 Configuring System Information
2. Click Show All to display the Remote Log Servers Table page .
Figure 6-21. Show All Log Servers
3. To remove a server, check the corresponding Remove check box.
4. Click Apply Changes .
The server is removed, and the device is updated.
Working with Remote Server Logs Using CLI Commands
For information about the CLI commands that perform this function, see the Syslog Commands chapter
in the
CLI Reference Guide . The following table summarizes the equivalent CLI commands you use to
work with remote server logs.
Defining IP Addressing
Use the IP Addressing page to assign management interface and default gateway IP addresses, negotiate
with the Domain Name System, set a Default Domain Name, perform Host Name Mapping, and define
ARP and DHCP parameters for the interfaces.
To display the IP Addressing page, click System
→ IP Addressing in the tree view. Use this page to go to
the following features:
•Out of Band Interface
• Domain Name Server (DNS)
• Default Domain Name
•Host Name Mapping
• Dynamic Host Name Mapping
Table 6-14. Remote Server Logs Commands
CLI Command Description
logging facility Use to set the facility for logging messages.
logging
<host> Logs messages to the specified syslog server.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
