Dell PowerConnect 8024 User Guide

56 Hardware Description
System LEDs
The system LEDs, located on the back panel, provide information about the power supplies, thermal
conditions, and diagnostics. The following table contains the System LED definitions.
SFP/SFP+ Port LEDs
The following table contains SFP/SFP+ port LED definitions for the PowerConnect 8024/8024F
switches.
Table 4-3. System LED Definitions
LED Color Definition
DIAG Flashing Green A diagnostics test is in progress.
Green The diagnostics test was successfully completed.
Red The diagnostics test failed.
PWR Green Power Supply is operating correctly.
Red Power Supply has failed.
FAN Green Fans are operating correctly.
Red One or more fans have failed.
Temp Amber System temperature has exceeded threshold limit.
Table 4-4. SFP/SFP+ Port LEDs Definitions
LED Color Definition
LNK/ACT Solid Green The port is linked.
Flashing Green The port is sending and/or receiving network traffic.
Off The port is not linked.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
