Dell PowerConnect 8024 User Guide

44 Using Dell™ OpenManage™ Switch Administrator
Console Connection
See "Serial Cable Connection" on page 48 for a description of the required console cable.
1.
Turn on the switch and wait until the startup is complete.
2. If the admin has not configured a login authentication method, then the console> prompt displays
when the switch boots up. Otherwise, the user is presented with the
User: login prompt.
NOTE: The following steps assume that the admin user and password is configured on the system.
3. Ty p e admin at the prompt, and press <Enter>.
The
Password : prompt now displays.
4. Enter the password, which displays as asterisks (*).
The
console# prompt now displays.
5. Configure the device and enter the necessary commands to complete the required tasks.
6. When finished, exit the session with the quit or exit command.
Telnet Connection
Telnet is a terminal emulation TCP/IP protocol. ASCII terminals can be virtually connected to the local
device through a TCP/IP protocol network. Telnet is an alternative to a local login terminal where a
remote login is required.
Your switch supports up to four simultaneous Telnet sessions. All CLI commands can be used over a
telnet session.
Using the CLI
Command Mode Overview
The CLI is divided into command modes. Each command mode has a specific command set. Entering a
question mark at the console prompt displays a list of commands available for that particular command
mode.
In each mode, a specific command is used to navigate from one command mode to another.
During the CLI session initialization, the CLI mode is the User EXEC mode. Only a limited subset of
commands are available in the
User EXEC mode. This level is reserved for tasks that do not change the
switch configuration and is used to access configuration sub-systems. Privileged EXEC mode may
require a password if the enable password is configured. See "Security Management and Password
Configuration" on page 77 for more information on setting up enable passwords.
The
Privileged EXEC mode provides access to the device global configuration. For specific global
configurations within the device, enter the next level, Global Configuration mode. A password is not
required.
The
Global Configuration mode manages the device configuration on a global level.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
