Dell PowerConnect 8024 User Guide

558 Configuring Routing
Configuring Router Discovery Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• Router Discovery Protocol Commands
The following table summarizes the equivalent CLI commands for this feature.
Router Discovery Status
Use the Router Discovery Status page to display Router Discovery data for each port.
To display the page, click Routing
→ Router Discovery → Status in the tree view.
Table 9-29. Router Discovery Commands
CLI Command Description
ip irdp Enables Router Discovery on an interface.
ip irdp address Configures the address that the interface uses to send the router
discovery advertisements.
ip irdp holdtime Configures the value, in seconds, of the holdtime field of the router
advertisement sent from this interface.
ip irdp maxadvertinterval Configures the maximum time, in seconds, allowed between sending
router advertisements from the interface.
ip irdp minadvertinterval Configures the minimum time, in seconds, allowed between sending
router advertisements from the interface.
ip irdp preference Configures the preference of the address as a default router address
relative to other router addresses on the same subnet.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
