Dell PowerConnect 8024 User Guide

Configuring System Information 195
Displaying the User Group Page
1. Open the User Group page.
2. Click Show All .
The
User Group Summary page displays:
Figure 6-76. CP User Group Summary
3. To remove a configured group, select the Remove option in the appropriate row, and then click Apply
Changes
.
Interface Association
From the Interface Association page, you can associate a configured captive portal with specific
interfaces. The captive portal feature only runs on the interfaces that you specify. A captive portal can
have multiple interfaces associated with it, but an interface can be associated to only one CP at a time.
To view the Interface Association page, click System
→ Captive Portal → Interface Association.
Figure 6-77. CP Interface Association
The Interface Association page contains the following fields:

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
