Dell PowerConnect 8024 User Guide

Configuring Switching Information 427
• Sender IP Address — To create a new rule for the selected ARP ACL, enter in this field the Sender IP
Address match value for the ARP ACL.
•
Sender MAC Address — To create a new rule for the selected ARP ACL, enter in this field the Sender
MAC Address match value for the ARP ACL.
Displaying the DAI ACL Rule Summary Table
1. Open the DAI ACL Rule Configuration page.
2. Click Show All .
The
Dynamic ARP Inspection ACL Rule Summary table displays.
Figure 7-112. Dynamic ARP Inspection Rule Summary
Configuring Dynamic ARP Inspection Rule With CLI Commands
For information about the CLI commands that perform this function, refer to the following chapter in
the
CLI Reference Guide :
• Dynamic ARP Inspection Commands
The following table summarizes the equivalent CLI commands for this feature.
DAI Statistics
Use the DAI Statistics page to display the statistics per VLAN.
To display the DAI Statistics page, click Switching
→ Dynamic ARP Inspection → Statistics in the
navigation tree.
Table 7-62. Dynamic ARP Inspection Rule Command
CLI Command Description
permit ip host mac host Configures a rule for a valid IP address and MAC address combination
used in ARP packet validation.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
