Dell PowerConnect 8024 User Guide

752 Configuring IP Multicast
• Version 1 Querier Timeout — The older MLD version 1 querier timeout value in
hours:minutes:seconds. The Older Version Querier Interval is the time-out for transitioning a host
back to MLD mode once an older version query is heard. When an older version query is received,
hosts set their Older Version Querier Present Timer to Older Version Querier Interval.
•
Proxy Start Frequency — The number of times the proxy was brought up.
Click Refresh to refresh the data on the screen with the present state of the data in the router.
Click Clear Statistics to clear the MLD Proxy Interface statistics and reset the counters to their original
values.
Displaying IPv6 MLD Proxy Summary Information Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• IPv6 Routing Commands
The following table summarizes the equivalent CLI commands for this feature.
Interface Membership Information
The Interface Membership Information page lists each IP multicast group for which the MLD proxy
interface has received membership reports. To display this page, click IPv6 Multicast
→ MLD → Proxy
interface
→ Interface Membership Info in the navigation tree.
Table 12-29. IPv6 MLD Proxy Summary Command
CLI Command Description
show ipv6 mld-proxy Displays a summary of the host interface status parameters.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
