Dell PowerConnect 8024 User Guide

750 Configuring IP Multicast
• Interface — Select the interface for which data is to be displayed or configured from the menu. You
must have configured at least one router interface before configuring or displaying data for an MLD
Proxy interface and it should not be a MLD routing interface.
•
Interface Mode — Select enable or disable from the menu to set the administrative status of MLD
Proxy on the selected interface. The default is disable. Routing, MLD and Multicast global admin
modes should be enabled to enable MLD Proxy interface mode.
•
Unsolicited Report Interval — Enter the unsolicited time interval value in seconds. The Unsolicited
Report Interval is the time between repetitions of a host's initial report of membership in a group. Valid
values are from (1 to 260). The default value is 1.
Click Apply Changes to send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is performed.
Configuring MLD Proxy Global Settings Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• IPv6 Routing Commands
The following table summarizes the equivalent CLI commands for this feature.
MLD Proxy Configuration Summary
Use the MLD Proxy Configuration Summary page to view configuration and statistics on MLD proxy-
enabled interfaces. To display this page, click IPv6 Multicast
→ MLD → Proxy Interface → Configuration
Summary in the navigation tree.
Table 12-28. IPv6 MLD Proxy Global Commands
CLI Command Description
ipv6 mld-proxy Enables MLD Proxy on the router.
ipv6 mld-proxy reset-status Resets the host interface status parameters of the MLD Proxy router.
ipv6 mld-proxy unsolicit-rprt-interval Sets the unsolicited report interval for the MLD Proxy router.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
