Dell PowerConnect 8024 User Guide

718 Configuring IP Multicast
Displaying DVMRP Configuration Summary Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• DVMRP Commands
The following table summarizes the equivalent CLI commands for this feature.
Next Hop Summary
Use the Next Hop Summary page to display or print the next hop summary by Source IP.
To display the page, click IPv4 Multicast
→ DVMRP → Next Hop Summary in the tree view.
Figure 12-11. Next Hop Summary
The Next Hop Summary page displays the following fields:
• Source IP — Displays the IP address used with the source mask to identify the source network for this
table entry.
•
Source Mask — Displays the network mask used with the source IP address.
•
Next Hop Interface — Displays the outgoing interface for this next hop.
Table 12-10. DVMRP Configuration Summary Commands
CLI Command Description
show ip dvmrp interface Displays the interface information for DVMRP on the specified
interface.
show ip dvmrp neighbor Displays the neighbor information for DVMRP.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
