Dell PowerConnect 8024 User Guide

Configuring System Information 175
RADIUS Accounting Server Statistics
Use the RADIUS Accounting Server Statistics page to view statistical information for each RADIUS
accounting server configured on the system.
To access the RADIUS Accounting Server Statistics page, click System
→ Management Security →
RADIUS
Accounting Server Statistics in the tree view.
Figure 6-61. RADIUS Accounting Server Statistics
The RADIUS Accounting Server Statistics page contains the following fields:
• RADIUS Accounting Server Host Address — Use the drop-down menu to select the IP address of the
RADIUS accounting server for which to display statistics.
Table 6-33. RADIUS Accounting Server Commands
CLI Command Description
acct-port Sets the port number for the designated radius accounting server.
key Sets the authentication and encryption key for all RADIUS
communications between the switch and the RADIUS daemon.
name Assigns a name to a RADIUS accounting server.
radius-server acct Specifies a RADIUS accounting server host and enter RADIUS Server
Configuration mode.
show radius-servers Displays the RADIUS accounting server settings.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
