Dell PowerConnect 8024 User Guide

Configuring System Information 119
Defining SNTP Authentication Settings Using CLI Commands
For information about the CLI commands that perform this function, see the Clock Commands chapter
in the
CLI Reference Guide . The following table summarizes the equivalent CLI commands you use to
define SNTP authentication settings.
SNTP Server
Use the SNTP Server page to view and modify information for enabling SNTP servers, and to add new
SNTP servers.
To display the SNTP Server
page, click System → SNTP → SNTP Server in the tree view.
Figure 6-13. SNTP Servers
The SNTP Servers page contains the following fields:
• SNTP Server — Selects user-defined SNTP server IP address from a drop-down menu. Up to eight
SNTP servers can be defined by using the
Add button.
Table 6-9. SNTP Authentication Settings Commands
CLI Command Description
sntp authenticate Use to require server authentication for received Network Time
protocol (NTP) traffic.
sntp authentication-key Use to define an authentication key for SNTP.
sntp trusted-key Use to authenticate the identity of a system to which SNTP will
synchronize.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
