Dell PowerConnect 8024 User Guide

Configuring Routing 565
Static — Enter values for Network Address , Subnet Mask , Next Hop IP Address , and Preference .
Figure 9-38. Route Entry Configuration - Add Static Route Type
4. Click Apply Changes .
The new route is added, and you are redirected to the Configured Routes page.
Adding a Router Route Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• IP Routing Commands
The following table summarizes the equivalent CLI commands for this feature.
Configured Routes
Use the Configured Routes page to display the routes that have been configured.
To display the page, click Routing
→ Router → Configured Routes in the tree view.
Table 9-33. Router Route Configuration Commands
CLI Command Description
ip route Configures a static route. Use the no form of the command to delete
the static route.
ip route default Configures the default route. Use the no form of the command to
delete the default route.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
