Configuring IP Multicast 719
•
Ty p e
— Displays the next hop type. Leaf means that no downstream dependent neighbors exist on the
outgoing interface. Otherwise, the type is Branch.
Displaying the Next Hop Summary Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• DVMRP Commands
The following table summarizes the equivalent CLI commands for this feature.
Prune Summary
Use the Prune Summary
page to display or print the prune summary by Group IP.
To display the page, click IPv4 Multicast
→
DVMRP
→
Prune Summary in the tree view.
Figure 12-12. Prune Summary
The Prune Summary page displays the following fields:
Table 12-11. DVMRP Next Hop Command
CLI Command Description
show ip dvmrp nexthop D
isplays the next hop information on outgoing interfaces for
routing multicast datagrams.
