642 Configuring IPv6
• LS Acknowledgements Received — The number of LS acknowledgements received on this interface
by this router.
Displaying OSPFv3 Interface Statistics
1. Open the OSPFv3 Interface Statistics page.
2. Select the interface to display from the Interface drop-down menu.
Statistics for the interface display.
Displaying OSPFv3 Interface Statistics Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• OSPFv3 Commands
The following table summarizes the equivalent CLI commands for this feature.
OSPFv3 Neighbors
Use the OSPFv3 Neighbors page to display the OSPF neighbor configuration for a selected neighbor ID.
When a particular neighbor ID is specified, detailed information about that neighbor is given. Neighbor
information only displays if OSPF is enabled and the interface has a neighbor. The IP address is the IP
address of the neighbor.
To display the page, click IPv6
→ OSPFv3 → Neighbors in the tree view.
Table 10-18. OSPFv3 Interface Statistics Commands
CLI Command Description
show ipv6 ospf interface stats Displays the statistics for a specific interface.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
