550 Configuring Routing
Selecting an Authentication Method
1. Open the RIP Interface Configuration page.
2. Specify the interface for which the authentication method is to be configured.
3. Click Modify .
The Authentication Method page displays.
4. Specify the Authentication Type (None, Simple, or Encrypt) from the drop-down menu.
5. If you specify Simple or Encrypt as the Authentication Type, additional fields appear. Enter the
Authentication Key (Simple or Encrypt) and Authentication Key ID (Encrypt).
6. Click Apply Changes .
7. The authentication method is updated, and the device is updated.
Configuring the RIP Interface with the CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• Routing Information Protocol (RIP) Commands
The following table summarizes the equivalent CLI commands for this feature.
RIP Interface Summary
Use the RIP Interface Summary page to display RIP configuration status on an interface.
To display the page, click Routing
→ RIP → Interface Summary in the tree view.
Table 9-25. RIP Interface Configuration Commands
CLI Command Description
ip rip Enables RIP on a router interface.
ip rip authentication Sets the RIP Version 2 Authentication Type and Key for the specified
interface.
ip rip receive version Configures the interface to allow RIP control packets of the specified
version(s) to be received.
ip rip send version Configures the interface to allow RIP control packets of the specified
version to be sent.
show ip rip interface Displays information related to a particular RIP interface.
