Dell PowerConnect 8024 User Guide

Configuring Routing 543
The UDP/Helper Relay is added to the interface and the device is updated.
Configuring IP Helper Interfaces Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• IP Helper Commands
The following table summarizes the equivalent CLI commands for this feature.
IP Helper Statistics
Use the IP Helper Statistics page to view UDP Relay Statistics for the switch.
To display the page, click Routing
→ IP Helper → Statistics in the tree view.
Figure 9-26. IP Helper Statistics
The IP Helper Statistics page contains the following fields:
• DHCP Client Messages Received — The number of valid messages received from a DHCP client.
The count is only increased if IP helper is enabled globally, the ingress routing interface is up, and the
packet passes a number of validity checks, such as having a TTL >1 and having valid source and
destination IP addresses.
Table 9-22. IP Helper Interface Commands
CLI Command Description
ip helper-address (interface configuration) Configures the relay of certain UDP broadcast packets received on a
specific interface.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
