Dell PowerConnect 8024 User Guide

304 Configuring Switching Information
Adding Protected Port Groups
1. Open the Protected Port Configuration page.
2. Click Add .
The
Add Protected Group displays.
Figure 7-24. Add Protected Port
3. Use the drop-down menu to assign the numeric designation 0, 1, or 2 to the Protected Group ID .
4. Enter a Protected Group Name (1–32 characters) .
5. Click Apply Changes .
The Protected Group settings are copied, and the device is updated.
Configuring Protected Ports With CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• Switchport Protected Commands
The following table summarizes the equivalent CLI commands for this feature.
LAG Configuration
Link Aggregation allows one or more full-duplex Ethernet links to be aggregated together to form a Link
Aggregation Group (LAG). The switch can treat LAG as if it were a single link.
To display the LAG Configuration page, click Switching
→ Ports → LAG Configuration in the tree view.
Table 7-13. Protected Port Commands
CLI Command Description
show switchport protected Displays protected group/port information.
switchport protected Configure a protected port.
switchport protected name Configures a name for a protected group

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
