Dell PowerConnect 8024 User Guide

Configuring Switching Information 303
Figure 7-22. Protected Port Configuration
The Protected Port Configuration page contains the following fields:
• Port — Specifies the Unit and Port for which port parameters are defined.
•
Protected Group ID — Drop-down menu used to assign a port to Group 0, 1, or 2.
•
Remove Group Name — Check this box to disassociate the selected port from the protected group.
Displaying the Protected Port Table
1. Open the Protected Port Configuration page.
2. Click Show All .
The
Protected Ports Summary table displays.
Figure 7-23. Protected Port Summary Table
3. Select the Remove check box and click Apply Changes to disassociate a port from a protected group.
4. Use the Unit drop-down menu to view the Protected Port Summary table for other units in the stack,
if they exist.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
